Hotplate Stirrers(Multi-position)




● Performance & Convenience


▶ Ideal for the multiple sample testing under the same condition.

- Maximum 15 independently controlled stirring positions on one heated top plate.

▶ User-friendly operation and time setting modes allowing various ways of multi-position stirring to meet users’ demands: single point, multiple point, whole row, whole column, etc.

▶ Integrated design of the heater and the top plate provides exceptional heat transfer rate and quick heat up capability.

▶ Fast and precise stirring operations are enabled by BLDC motor and special magnet with extremely strong magnetic coupling power.

▶ Smooth-start mechanism provides virtually no decoupling of stir bars even with viscous media.

▶ Instant halt of the stirring operation.

▶ Easy-to-read VFD and intuitive control panel.

▶ Bright and vivid LED stirring position indicating lamps and heating operation lamp for stable operations.

▶ High heat transfer aluminum top-plate.



● Safety


▶ Unit is safely designed to protect internal components from accidental spills.

▶ Non-slip silicon plate mat is attached on the top plate to prevent unintended slips

▶ Built in thermal shut off and current limit protection.


Model

MS-33MH

MS-53MH

Heating

Temperature range (℃ / ℉)

Max. 120 / 248

Control

Scale

Heating power (W)

600

1000

Stirring

Speed range (rpm)

30 to 2,000

Control

Feedback control with PID

Stirring position

9

15

Stirring point distance (WxD, mm / inch)

117x90 / 4.61x3.54

Timer

1min. to 99 hr. 59 min.

Motor

BLDC motor

Motor rating input / output (W)per each point

2.9/1.6

Magnetic bar, Max. (ØxL, mm / inch)

8x30 / 0.31x1.18

Safety

Over temp.

Top plate

Over current

Current limit protection

Load, Max (kg / Ibs)

30 / 66.14

Top plate

Material

Aluminum

Dimension (WxD) (mm / inch)

385x328 / 15.16x12.91

385x493 / 15.16x19.41

Body

Material

Powder coated steel

Dimension (WxDxH) (mm / inch)

395x450x104 / 15.55x17.72x4.09

395x614x104 / 15.55x24.17x4.09

Net weight (kg / Ibs)

10 / 22.05

15 / 33.06

Electrical requirements (230V, 50/60Hz)

4.1 A

5.8 A

Cat. No.

AAHK34015K

AAHK34025K

Electrical requirements (120V, 60Hz)

8.0 A

11.2 A

Cat. No.

AAHK34013U

AAHK34023U
