ELcoat® TE
- High conductive coating
- ELcoat® TE is an intensive coating material with the high conductive performance of 50~400Ω/■ as for replacement and/or composite with current high conductive materials ITO, Ag nanowire, Graphene etc. ELcoat® TE is a complete solutions for flexible TSP & display through readily coating on various substrates and it is a remarkable materials to substitute ITO for smart windows as well.
● Products
- ELcoat® TE 2083 : Coating solution for smart window (PDLC) electrode film / 150~270Ω/■, Solvent resistance
- ELcoat® TE 3083 : Coating solution for LCD Writing(Boogie) Board electrode film / 150~400Ω/■
- ELcoat® TE 1000 : Coating solution for Transparent Conductive Film / 150, 270Ω/■
- ELcoat® TE 500 : Coating solution for automotive lamp interior / 200~400Ω/■, Spray coating
● Features
- Excellent optical property
- High production yield
- Good durability
- Roll to Roll(easy coating), Spray coating
● Property – PEDOT:PSS Base
Grade | ELcoat® TEA Heat cure type | ELcoat® TEU UV cure type |
---|
Solid Content (%) | 0.5~1.0 | 2.0~3.0 |
Surface Resistance (Ω/■) | 50~400 | 150~400 |
Haze (%) | < 1.0 | < 1.0 |
Transmittance (%) | 80~92 | 82~92 |
Taping Test | 100/100 | 100/100 |
Coating Method | Gravure & Slot die | Slot die |
Curing Condition (Lab) | 120℃Ⅹ3min or 80℃Ⅹ1min + 60℃Ⅹ72hr | 100℃Ⅹ1min → UV 500mJ/㎠ |
Solvent Resistance | Excellent | Excellent |
Durability (60℃, RH90%, 240hr) | Surface resistance changes, less than 10% | Surface resistance changes, less than 10% |
Etching | Wet or Dry etching | Dry etching |
Coating property measured with PET film (100㎛)
